WIDESPAN HEAVY DUTY SHELVING SYSTEM

Key features:
  • Several widths, depths and heights available
  • Up to 1500 lbs capacity
  • Shelf available: wood, wire mesh, metal
Ideal for:
  • Products with large volume per SKU
  • Typical application: e-commerce, apparel, auto parts, archiving

Long-span heavy-duty shelving is designed for the storage of bulky items. By using a steel frame and economical wooden shelves, this solution offers the user the opportunity to reduce expenses while maintaining good storage capacity for larger items.

The widespan heavy-duty shelving is quick to install, offers good value for money and is sold in different depths, widths and heights, as well as different shelving surfaces such as wood, wire mesh and steel. Ideal for large-scale storage, the dimensions of widespan heavy-duty shelving are adapted to the dimensions of classic archive boxes.

What are the advantages of long-span warehouse shelving?

Widespan heavy-duty shelving has many advantages over traditional metal shelving. Here are a few:

Widespan heavy-duty shelving are wider

As their name suggests, widespan heavy-duty shelving are available in widths up to 96”, unlike traditional shelving which is up to 48”. This makes it possible to store much larger parts on the same shelf, without going with traditional pallet racking whose capacity is much too high for several applications.

Widespan heavy-duty shelving are accessible from both sides

Unlike traditional metal shelving, which usually has a closed back panel or X-bracket, widespan heavy-duty shelving have no central structure, allowing your employees to pick parts from either side without issue. This increases the versatility of widespan heavy-duty shelving as different types of products can be stored.

Widespan heavy-duty shelving offer multiple shelving options

A final benefit of widespan heavy-duty shelving is that they offer multiple shelf options: high-capacity metal shelves, wire mesh to maximize ventilation and limits dust accumulation or wood, for lower capacity applications. This allows you to customize the configuration to the specific characteristics of your application.

Image with detail index:

  1. WOOD SHELF: Wood shelves for the widespan line are available in a multitude of sizes to meet your requirements. Wire mesh or solid steel shelves are also available.
  2. TIE BAR: Tie bars are designed to avoid buckling on longer beams. Placed between the two beams, they will also increase the capacity of the level.
  3. FRAME CONNECTOR: Frame connectors are used to connect posts together from front to back. Refer to capacity charts to determine the number of connectors required.
  4. POST : A 14-gauge roll formed post with 2” slots to allow easy adjustability of the unit’s height. Splice posts together to create a mezzanine catwalk system.
  5. BEAM: 2” profile beams made of 13-gauge steel are the main shelf support. Available in a variety of widths and capacities.
  6. FOOT PLATE: Foot plates are used to anchor the units to the floor. Highly recommended for units of 8 feet or taller.
